Thermal Grizzly KryoSheet Thermal Pad - 29 x 25 mm

Thermal Grizzly CRYOSHEET - 29 X 25 MM - 0.2 MM

The graphene thermal pads of the Thermal Grizzly KryoSheet series can be used as an excellent alternative to thermal pastes from the higher performance segment. Similar to the Carbonaut pads, they have an adaptable surface with very high thermal conductivity. Compared to Carbonaut pads, KryoSheet, as a high-end product, offers significantly higher thermal conductivity. This increased thermal conductivity is not only due to the choice of material, but also to the innovative manufacturing process. KryoSheet does not contain any liquid components and is therefore not subject to normal aging as is the case with traditional thermal paste. It cannot dry out.

• Outstanding thermal conductivity
• Simple application
• Consistently high performance
• Extreme durability
• Caution: Electrically conductive! Follow instructions!

The KryoSheet graphene pads have a molecular structure stacked in the Z direction. This optimized structure enables outstanding and constant thermal conductivity. This is due to a specially developed manufacturing process in which the hexagonal crystal structure of the graphite is broken up along the basal plane in order to exploit the anisotropy of the thermal conductivity of the graphite. As a side effect of this complex manufacturing process, however, the electrical conductivity is also increased and the stability of the KryoSheet pads is affected, so the pads should only be used according to the instructions!

KryoSheet is available pre-assembled in various CPU/GPU standard sizes, e.g.:

KryoSheet 29 x 25 mm Compatibility

Nvidia GPUs:
RTX 4090
RTX 3080, RTX 3080ti, RTX 3090, RTX 3090ti
RTX 2070, RTX 2080, RTX 2080

AMD GPUs:
RX 7900 XT, RX 7900 XTX
RX 6800, RX 6800 XT, RX 6900 XT, RX 6950 XT

Intel GPUs:
Arc-A750, Arc-A770

Note: We do not recommend using KryoSheet more than once!
Disassembling the cooler and handling the KryoSheet after use may cause microcracks in the structure of the graphene pads, which may affect performance.
